Wide Track-Mount Overhead-Door Metal Magnetic Contact:  Designed for panel or sectional style overhead doors, Rugged aluminum housing, IP65 weatherproof, 1000mm armored cable, Easy to installation. Suitable for all kinds of overhead doors in both industrial and residential situations, where a wide gap is present.

- 50~60mm Gap for overhead doors in both industrial and residential situations, where a wide gap is present

- Rugged aluminum housing, IP65 weatherproof

- 39″ (100cm) Wire leads enclosed in armored cable

- Contact type: iridium-plated to have a high melting point and Vickers hardness for higher power handling and longer expected life

- Left or right installation, Mounting bracket included

- Hinge design for tighter clamping to track

- Reversible probe assembly

• Housing material:   Metal(Alloy-Zn ), grey

• Connecting mode: N.C/ Wire ((N.O.& changeover available)


• Operating distance(Gap): 50-60mm

• Cable length: 1000mm armored cable

• Max. Voltage/Current: 100V/0.5A

• Mounting: Surface mount


• Dimension:    47LXΦ13mm


• Package:    1set/PE,  each part packed individually

Package Contents:

• Standard Exporting Packing Box
