Waterproof Metal Card Reader: ZDR-2400W

Waterproof Metal Card Reader

MODELZDR-2400W

Facebook Twitter InLink instagram Youtube Skype
  • Waterproof, conforms to IP68, Backlight keys

  • Exquisite designs with non-masking Metal shell

  • Reading Mode: 125KHz EM-ID Card; or 13.56 MHz Mifare-ID optional

  • Proximity Range: 3-15cm

  • Output Format: Wiegand 26/34

  • Response Speed: Less than 0.2 second;

  • Proximity Time Distance: Less than 0.5 seconds

Waterproof Metal Card Reader: IP68 waterproof design, Backlight keys,RFID type ID access control card reader, Reading Distance is about 3-15CM; Support Wiegand 26bits/ Wiegand34bits /ABA Standard Format Data Output. It's widely use for Access control, Parking lot, Campus ID, Time attendance, Hotel Management.



Support ID (125KHz) EM Card or IC Mifare Card (13.56 MHz Frequency)

- IP68 Waterproof design

- Built-in Antenna
Built-in LED (Double Color LED)
-
 Built-in Loud Speaker (Buzzer)
- 100 Meters Communication Distance
Real Time Data Transfer.



  • Exquisite designs with non-masking Metal shell: Metal shell

  • Keystroke backlight

  • Reading Mode: 125KHz EM-ID or 13.56 MHz Mifare-ID optional

  • Proximity Range: 3-15cm

  • Output Format: Wiegand 26/34, RS485/232

  • Communication Distance: WG≤100M, RS485≤1200M

  • Response Speed: Less than 0.2 second; Proximity Time Distance: Less than 0.5 seconds :

  • Wiring connection:
    Red: DC5V~16V; Black: GND; Blue: D1; White: D0; Brown: Beep; Green: LED; Yellow: Alarm

  • Working Voltage: DC12V; Working Current: 70mA

  • Color: Silver Color

  • Temperature: -25℃ to 75℃; Humidity: 10%-90%

  • Product Size: 143mm x 58mm x 25mm



                  Waterproof Metal Card Reader(图1)


Package Contents:

  • Standard Exporting Packing Box
