Facial & Fingerprint Time Attendance: ZDTA-F51
Multi-Angle View
Multi-Angle View
Multi-Angle View

Facial & Fingerprint Time Attendance Terminal

MODELZDTA-F51

Facebook Twitter InLink instagram Youtube Skype
  • AI Dynamic Face recognition with Access Control

  • Face capacity:5000

  • Fingerprint capacity: 5000

  • IC Mifare Card :5000

  • Password capacity: 5000

  • Record capacity:500,000

  • Display:5 inch TFT touch panel

  • Camera:double HD Infrared camera

  • Verify mode:Face,Fingerprint, Password, IC card


Facial & Fingerprint Time Attendance Terminal:  5" touch screen, AI Dynamic Face recognition, 5000 face +5000 fingerprint capacity, fast recognition speed less than 0.02s, Single user/Mulit-user recongition, Face/Fingerprint/Password/ IC card multiple  Access Control verify mode, and many more powerful functions.  It's widely used for Passenger Turnstile, Government Institution, Office, Building, Apartment,Community, and factory etc.


Facial & Fingerprint Time Attendance Terminal(图1)

- Dynamic Face recognition with Access Control

- Face capacity:5000

- Fingerprint capacity: 5000

- IC Mifare Card:5000

- Password capacity: 5000

- Record capacity:500,000

- Display:5 inch TFT touch panel

- Camera:double HD Infrared camera

- Verify mode:Face,Fingerprint, Password, IC card

- Communication:USB/U-disk/TCP/IP(WiFi optional)

- Voltage/current:DC9V~12V/1A

- Recognition distance: 0.5~2.5m(0.5~1.5m with live face recognition on.)

- Access Control funtion: Wiegand26/34, Door Lock, Siren, Release Button, Door Sensor, Doorbell function


ModelZDTA-F51
Product nameAl Dynamic Face   Recognition Time Attendance Access Control Terminal
Screen5.0  Inch, HD 1280*720, Capacitive Touch Screen
KeypaTouch keypad
Operation   systemLINUX 3.10
CPU,NPU1.2G Dual-Core ARM   Cortex-A7, 6000 (0.6T)
RAM256MB DDR3
ROMeMMC Flash 4GB
Binocular   camera200W Colorful   WDR+200W Infrared live camera
Logs   capacity 500000
Face   RegistrationLocal   operation: Enroll face with machine, impot user photo with U disk
    Sofware operation: Import user photo to sofware, capture user photo with   camera
VerificationDynamic face   recognitin, password, ID/IC card optional
Face capacity5000 (50000 optinal)
Fingerprint   capacity5000 (50000 optinal)
Card Capacity5000 (50000 optinal),   ID Card Standard, IC Card Optional
Password   Capacity5000 (0000 optinal)
Face   Recognition Accuracy99.70%
Recognition   Speeds0. 2s, support   single user/muti user(at most 5 users) recognition at same time
Recognition   Distance0.5~2.5 meters   (0.5~1.5 meters with live face recgnition on)
Prevent PhotoDual camera   anti-counterfeiting, prevent recognition with photo/video
Principle of   IdentificationFace   algorithm technology of multi-task cascaded convolutional neural network   based on
    video stream for dynamic face detection, tracking and recognition
WDRWide dynamic range,   support accurate face recognition under Strong light, dark light and   backlight
USBUSB2.0x1. Support U   disk import/export data
Power supplyDC12V interfacex 1
Speaker   InterfaceReserved for extended   Speaker Interface
Network   CommunicationTCP/IP, Support C/S   LAN communication, Wifi (opional)
Free   Attendance softwareSupport exporting   excel atendance report with U disk
ShiftSupport shit stting   and importing shift schedule with U disk
Management   SoftwareSupport PC sofware to   manage data through network connection with equipment
Access   Control FunctionDoor   unclosed alarm, forced door opening alarm, alarm linkage and output, one set   of door opening signals,one set of alarm signals, time permission control,   connect external access control reader,Wegand 26/34 output input
Environmental   adaptabilityWorking   temperature: -15C~ +45°C (storage temperature -40°C~+65C)
Working humidity: 20%~90% (storage humidty   20%~90+2%)
Dark enviroment: LED Soft light automatic fl   light (Automatic control according to ambient light)
Ambient light adaptation range: 0-50000LuX
Multi languageEnglish, Spanish,   Arabic, Thai, Farsi, Portuguese, French, ltalian, Japanese, Korean, etc
Broadcase and   ringSupport display name,   voice broadcase name, builin bell ring
Automatic fll   lightSupport infrared fl   light, the white fl light automatcally lights up when face is captured in   dark light
Working   Currentstand- by current:   310mA , Working current: 520mA
QR Code   ScannerSupport
Working   VoltageDC12V
Installation   WayStandard: Wall mount,   desktop stand; Optional: bracket for turnstile, floor stand
Device   Dimension188x80x20mm


Package Contents:

  • Standard Exporting Packing Box
