Waterproof Access Control:ZDAC-2500W
Multi-Angle View
Multi-Angle View

Metal Shell Access Controller -Waterproof

MODELZDAC-2500W

Facebook Twitter InLink instagram Youtube Skype
  • Waterproof, conforms to IP68, Backlight keys

  • Exquisite designs with non-masking Metal shell

  • Keystroke backlight

  • Card appliance: 125kHz EM ID cards

  • WG26 output, can be used as a Access reader.

  • 2000 uses, supports Card, PIN, Card + PIN

Waterproof Standalone Access Controller: IP68 Waterproof design, Exquisite designs with non-masking Metal shell, Keystroke backlight,Wiegand output. Supports up to 2000 users in either a Card, 4 digit PIN, or a Card + PIN option, with Doorbell function. These powerful features make ZDAC-2500 an ideal choice for door access not only for small shops and domestic households but also for commercial and industrial applications such as factories, warehouses, laboratories, banks and prisons.


Metal Shell Access Controller -Waterproof(图1)




- Waterproof, conforms to IP68, Backlight keys
- Exquisite designs with non-masking Metal shell
- Keystroke backlight
- Card appliance: 125kHz EM ID cards
- WG26 output, can be used as a Access reader.
- 2000 uses, supports Card, PIN, Card + PIN
- Adjustable Door Output time, Alarm time, Door Open time
- Very low power consumption (30mA)
- Fast operating speed, <20ms with 2000 users
- Lock output current short circuit protection
- Easy to install and program
- Built in light dependent resistor (LDR) for anti tamper
- Built in buzzer, Doorbell key
- Red, Yellow and Green LEDS display the working status


Metal Shell Access Controller -Waterproof(图1)

Model

ZDAC-2500W

 Card Types EM or EM compatible
 Alarm output load<20mA
 Operating Voltage DC 12V±10%
 User Capacity2000
 Card Reading Distance 3~6cm
 Active Current<60mA
 Idle Current 25±5 mA
 Lock Output Load Max 3A
 Alarm Output Load Max 20A
 Environment  Conforms to IP68
 Operating Temperature -45℃~60℃
 Operating Humidity  10%- 90% RH
 Adjustable Door Relay time 0 -99 seconds
 Adjustable Alarm Time 0- 3 minutes
 Wiegand Interface Wiegand 26 bit
 Wiring Connections Electric Lock, Exit Button, External Alarm,External reader
 Keypad Housing Metal
 Dimensions L115 x W75x H25 mm
 Weight 500g


Package Contents:

  • Standard Exporting Packing Box
