Face capacity: 1000
Fingerprint capacity: 5000
Card capacity: 5000
Record capacity:300,000
Display:2.8inch TFT
Camera:double HD Infrared camera
Verify mode:Face, Fingerprint, Password, ID card
Communication:U-disk/TCP/IP
Voltage/current:DC9V~12V/1A
F07 he fingerprint attendance management system contains two parts: fingerprint time attendance terminal and attendance management software.Fingerprint time attendance terminal is for enrolling user fingerprints and normal attendance record. Attendance management software is for downloading attendance record from theterminal and managing the attendance record. Communication methods between the fingerprint time attendance terminal and the attendance management software in the Computer: USB, TCP/IP, and USB Flash
- Strictly follow the national security product standard. Suitable for the entrances and exits of appartment, multi-family houses,office, factory, hotel, school, etc.
- TCP/IP + USB Flash Drive Up/Download.
- Anti-dismantlement alarm, threatens alarm, unlock illegally alarm,not block alarm are available.
- Fingerprint / Card / Password / Fingerprint+Card / Fingerprint+Password / Card+Password / Fingerprint+Card+Password identification modes are all available.
-It's with the most advanced fingerprint arithmetic in the world, automatically analyze the tiny difference of the latest fingerprints vs. the precious fingerprints and update accordingly to ensure the high accuracy and the optimum speed of fingerprint recognition, the identification time is less than 1 second.
- The device is built-in ID card sensor(optional for IC card), validate freely by Card, fingerprint and password combination, access control is more flexible and securely.
- With multi-level validation, lock combination and anti-pass back function, it suitable to the high-security places like bank and military ect.
- Support U disk to download or upload attendance records and fingerprint data. User could enroll the fingerprint in one device, and share the enrollment information with other devices through the USB flash memory.
- TCP/IP communication, network connection is simple and convenient, support Push Technology, operate access control networking and data collection & share freely.
- With tamper alarm, over-time door opening alarm ect alarm functions
-Authentication modes are 1:1 and 1:N, user can register three fingers, max fingerprint capacity is 2,000 enrollment and 50,000 record
- Support English, French, Spanish, Korean ect different languages.
Model | ZDTA-F07 |
LCD Screen | 2.8 inch |
Camera | Double HD Infrared camera |
Fingerprint Sensor Resolution | 500DPI |
Authentication Method | Face, Fingerprint, Aassword, ID card(Optional for MIFARE card) |
Communication | TCP/IP, USB Memory Disk (WiFi optional) |
User Capacity | 1000 Face, 5000 Fingerprint/Card |
Records Capacity | 300000 events |
Software OS | XP/Win2003/Vista/Win7/Win8 (32bit / 64bit) |
Language | English /Spanish /Thai /Arabic and so on |
Auto Output | Voice interface |
Search attendance log | Support(after authentication, user can look his/er attendance logs) |
Lock Output | Normal Open/Normal Close |
Self-test function | Supported |
Power | DC12V/1A |
FAR/ FRR | <0.0001% |
Identification Time | < 1S |
Operating Mode | Off-line/On-line |
Authentication Mode | 1:1, 1:N |
Operating environment | Operating Temp: 0ºC-50ºC, Humidity:80% |
Battery | 3 hours battery backup (optional) |
Matching mode | Supports 1: N |
Intelligent adaptation function | Support |
Package Contents:
Standard Exporting Packing Box
